Self Propelled Vertical Mast Lift | 8m Aerial Work Platform AMWP8-1100

  • Length: 1.41m
  • Width: 0.76m
  • Height: 1.99m
  • Platform Size: 0.78 × 0.70m
  • Extension Platform: 0.55m
Category:

The AMWP8-1100 self propelled vertical mast lift is a compact and efficient aerial work platform designed for indoor maintenance and warehouse operations.

With 8m working height, zero turning radius, and a lightweight design, this vertical mast lift is ideal for narrow spaces such as warehouses, shopping malls, and factories.

👉 Designed for single-person indoor aerial work

Key Advantages

Compact Design for Narrow Spaces

  • Width: 0.76m
  • Length: 1.41m
  • Zero turning radius (0m inner turn)

👉 Easily operates in elevators and tight aisles

Stable & Safe Operation

  • Emergency lowering system
  • Tilt alarm
  • Safety protection system

👉 Ensures safe operation in indoor environments

Efficient Electric Drive System

  • Battery powered (24V system)
  • Low noise & zero emission
  • Smooth driving even when elevated

Extension Platform for Better Reach

  • 0.55m extension deck
  • Increased working range without repositioning

👉 Improve efficiency for maintenance and installation work

Strong Performance

  • Working height: 8m
  • Load capacity: 150kg
  • Gradeability: 25%

👉 Ideal vertical lift for indoor maintenance and warehouse use

Specifications

Performance

ParameterAMWP8-1100
Working Height8.0m
Platform Height6.0m
Load Capacity150kg
Max Occupants1
Gradeability25%
Travel Speed (Stowed)4 km/h
Travel Speed (Raised)1.1 km/h

self propelled vertical mast lift 8m vertical lif

self propelled vertical mast lift 8m vertical lift

Dimensions

  • Length: 1.41m
  • Width: 0.76m
  • Height: 1.99m
  • Platform Size: 0.78 × 0.70m
  • Extension Platform: 0.55m

Power System

  • Battery: 2×12V / 85Ah
  • Drive Motor: 2×24V / 0.5kW
  • Lift Motor: 24VDC / 2kW

Applications

This compact vertical mast lift is widely used for:

  • Warehouse rack inspection
  • Factory equipment maintenance
  • Shopping malls & hotels
  • Airports & stations
  • Indoor installation and cleaning

👉 Best aerial work platform for narrow indoor spaces

Why Choose AMWP8-1100 Vertical Lift

✔ Ultra-compact size for tight spaces
✔ Extension platform for better reach
✔ Stable and safe lifting system
✔ Electric drive for indoor use
✔ Cost-effective aerial work solution

Related Equipment

FAQ – 8m Vertical Mast Lift

1. What is a vertical mast lift?

A vertical mast lift is a compact aerial work platform designed for lifting operators vertically in narrow indoor environments.

2. What is the working height of this lift?

This model provides a maximum working height of 8 meters, suitable for indoor maintenance and inspection tasks.

3. Is this lift suitable for warehouse use?

Yes, this self propelled vertical lift is ideal for warehouses due to:

  • Compact size
  • Zero turning radius
  • Electric operation

4. What is the load capacity?

The platform supports up to 150kg, suitable for one operator with tools.

5. Can it work in narrow spaces?

Yes, with its compact structure and zero turning radius, it is perfect for:

  • Elevators
  • Narrow aisles
  • Confined indoor environments

6. Is the platform extendable?

Yes, it features a 0.55m extension platform, allowing a wider working range.

7. Is it safe for indoor use?

Yes, it includes multiple safety features such as:

  • Emergency lowering system
  • Tilt alarm
  • Safety protection system

8. How to choose the right vertical lift?

Consider:

  • Working height
  • Load capacity
  • Space width
  • Indoor or outdoor use

👉 For compact indoor environments, this 8m vertical mast lift is an ideal choice

Call to Action

Looking for a compact and reliable vertical lift for indoor work?

👉 Contact us now to get:

  • Latest price
  • Product catalog
  • Fast delivery
